1-Year Limited Manufacturer Warranty
Covers hardware defects and failures due to manufacturing
Does not cover accidental damage, misuse, or unauthorized repairs
Proof of purchase is required for any claims
Warranty support handled by official Arduino customer service
Q: Does the Portenta H7 Lite support AI models?
A: Yes, it supports TensorFlow Lite for AI and ML applications.
Q: Is Wi-Fi and Bluetooth available on the Lite version?
A: No, the Lite version omits wireless modules to reduce cost.
Q: What processor does it use?
A: It features a Dual-core ARM Cortex-M7 + M4 STM32H747 processor.
Q: Can it be programmed with the Arduino IDE?
A: Yes, fully compatible with Arduino IDE and Arduino Cloud.
Ships within 3–5 business days across India via Bluedart/Delhivery
International shipping available via DHL/FedEx (5–10 business days)
Returns accepted within 7 days if product is unused and in original condition
Refund processed after quality check; customer covers return shipping (unless defective)
Reach out to support for RMA before initiating a return
🔧 Technical Specifications
| Processor | • Dual-core STM32H747 (ARM Cortex-M7 @480 MHz + Cortex-M4 @240 MHz) |
| RAM | • 8MB SDRAM |
| Storage | • 16MB NOR Flash |
| USB Connectivity | • USB-C port supporting power and programming |
| Power Supply | • 5V via USB-C or external battery |
| I/O Pins | • 22x digital I/O, 8x analog inputs, 1x DAC |
| Operating Voltage | • 3.3V logic level |
| Interfaces | • SPI • I2C • UART • CAN • PWM |
| Board Dimensions | • 102 mm x 25 mm |
| Other Features | • Castellated pins for SMT • Compatible with Portenta Vision Shield • Ideal for industrial & embedded applications |
